Cable Guide

Consolidated Cable Manufacturer Data
Wire Type Code Word AWG or MCM Strands Conductor   Dia. In.  AMPS ASK   Gauge
Compact Stranded   8 7 0.140 45 8
Compact Stranded   6 7 0.170 60
AAC Peachbell 6 7 0.184 103 6
AAAC Akron 30.58 7 0.198 107
ACSR Turkey 6 6/1 0.198 105
AAAC AKRON 30.58 7 0.198 107
AAAC KAZOO 30.58 7 0.198 107
CS    4 7 0.215 75
AAC Rose 4 7 0.232 138 4
AAAC Alton 48.69 7 0.250 143
AAAC  KAKI 48.69 7 0.250 X
ACSR Swan 4 6/1 0.250 140
ACSR Swanate 4 7/1 0.257 140
CS    2 7 0.270 100 2
AAC Iris 2 7 0.292 185
CS    1 18 0.305 115
CS   1 18 0.310 115
AAAC Ames 77.47 7 0.316 191
AAAC KENCH 77.47 7 0.316 X
ACSR Sparrow 2 6/1 0.316 184
AAAC Ames 77.47 7/w 0.316 191
ACSR Sparate 2 7/1 0.325 184
AAC Pansey 1 7  0.328 214
CS    1/0 18 0.340 135 1
ACSR Robin 1 6/1 0.354 212 1/0
ACSR Grouse 80.0 8/1 0.367 204
AAC Poppy 1/0 7 0.368 247
AAC Geranium 1/0 19 0.371 X
CS    2/0 18 0.380 150
AAAC Azusa 123.3 7 0.398 256 2/0
AAAC KIBE 123.3 7 0.398 X
ACSR Raven 1/0 6/1 0.398 242
AAAC Azusa 123.3 7/w 0.398 256
AAC Aster 2/0 7 0.414 286
AAC Buttercup 2/0 19 0.416 X
CS   3/0 18 0.430 175
AAAC Anaheim 155.4 7 0.447 296
ACSR Quail 2/0 6/1 0.447 276 3/0
AAAC  KAYAK 155.4 7 0.447 X
AAAC Anaheim 155.4 7/w 0.447 296
ACSR Petrel 101.8 12/7 0.461 237
AAC Phlox 3/0  7 0.464 331
AAC Primose 3/0 19 0.467 X
CS    4/0 18 0.480 205
ACSR Minorca 110.8 12/7 0.481 246
AAAC Amherst 195.7 7 0.502 342 4/0
ACSR Pigeon 3/0 6/1 0.502 315
AAAC  KOPECK 195.7 7 0.502 X
AAAC Amherst 195.7 7/w 0.502 342
AAC Oxlip 4/0 7 0.522 383
CS    250 35 0.525 230
AAC Sunflower 4/0 19 0.525 X
ACSR Leghorn 134.6 12/7 0.530 273
AAAC Alliance 246.9 7 0.563 395 250
AAAC  KITTLE 246.9 7 0.563 X
ACSR Penguin 4/0 6/1 0.563 357
AAAC Alliance 246.9 7/w 0.563 395
AAC Sneezewart 250 7 0.567 425
AAC Valerian 250 19 0.574 425
CS    300 35 0.575 255
AAC Dandelion 250 37 0.575 X
ACSR Guinea 159.0 12/7 0.576 297
AAC Daisy 266.8 7 0.586 443
AAC laurel 266.8 19 0.593 444
ACSR Dotterel 176.0 12/7 0.607 312 300
ACSR Waxwing 266.8 18/1 0.609 449
AAAC  RATCH 281.4 19 0.609 X
CS    350 35 0.620 280
AAC Peony 300 19 0.629 478
ACSR Dorking 190.8 12/7 0.631 324
AAAC Butte 312.8 19 0.642 460
ACSR Partridge 266.8 26/7 0.642 475
AAAC RAMIE 312.8 19 0.642 X
ACSR Cochin 211.3 12/7 0.664 340 350
CS    400 35 0.665 305
AAC Tulip 336.4 19 0.666 513
AAC Daffodil 350 19 0.679 526
ACSR Ostrich 300.0 26/7 0.680 492
AAC Gardenia 350 37 0.681 X
ACSR Merlin 336.4 18/1 0.683 519
AAAC RADAR 355.1 19 0.684 X
ACSR Brahma 203.2 16/19 0.714 341 400
ACSR Linnet 336.4 26/7 0.720 529
AAAC Canton 394.5 19 0.721 532
AAAC RADIAN 394.5 19 0.721 X
AAC Canna 397.5 19 0.724 570
CS   500 35 0.740 350
ACSR Oriole 336.4 30/7 0.741 535
AAAC REDE 419.6 19 0.743 X
ACSR Chickadee 397.5 18/1 0.743 576
AAC Goldentuft 450 19 0.769 616 477
ACSR Brant 397.5 24/7 0.772 584
AAAC Cairo 465.4 19 0.783 590
ACSR Ibis 397.5 26/7 0.783 587
AAAC  RAGOUT 465.4 19 0.783 X
AAC Cosmos 477 19 0.793 639
AAC Syringa 477 37 0.795 639
ACSR Lark 397.5 30/7 0.806 594
AAC Zinnia 500 19 0.811 658 500
AAC Hyacinth 500 37 0.813 658
ACSR Pelican 477.0 18/1 0.814 646
AAAC  REX 503.6 19 0.814 X
CS    600 58 0.820 385
ACSR Flicker 477.0 24/7 0.846 655
AAC Dahlia 556.5 19 0.856 703 600
AAAC Darien 559.5 19 0.858 659
ACSR Hawk 477.0 26/7 0.858 659
AAAC REMEX 559.5 19 0.858 X
AAC Mistletoe 556.5 37 0.858 704
ACSR Osprey 556.5 18/1 0.879 711
AAAC  RUBLE 587.2 19 0.879 X
CS    700 58 0.880 420
ACSR Hen 477.0 30/7 0.883 666
AAC Meadowsweet 600 37 0.891 738 700
AAC Lotus 600 61 0.893 X
ACSR Parakeet 556.5 24/7 0.914 721
AAC Orchid 636 37 0.918 765
CS   750 58 0.920 435
AAAC Elgin 652.4 19 0.927 729 556/636
ACSR Dove 556.5 26/7 0.927 726
AAAC ALIGN 652.4 19 0.927 X
AAAC RUNE 652.4 19 0.927 X
AAC Heuchera 650 37 0.928 775
ACSR Swift 636.0 36/1 0.930 769
ACSR Kingbird 636.0 18/1 0.940 773
ACSR Eagle 556.5 30/7 0.953 734
ACSR Peacock 605.0 24/7 0.953 760
AAC Verbena 700 37 0.963 812
AAC Flag 700 61  0.964 812
AAAC SURAL 704.6 37 0.966 X
ACSR Squab 605.0 26/7 0.966 765
AAC Violet 715.5 37 0.974 823
AAC Nasturtium 715.5 51  0.975 823
ACSR Rook 636.0 24/7 0.977 784
AAAC SPAR 740.8 37 0.990 X
ACSR Grosbeak 636.0 26/7 0.990 789
AAAC Flint 740.8 37 0.991
ACSR Wood Duck 605.0 30/7 0.994
ACSR Teal 605.0 30/19 0.994
AAC Petunia 750 37 0.997   750
AAC Cattail 750 61 0.998
ACSR Flamingo 666.6 24/7 1.000
ACSR Gannet 666.6 26/7 1.014
ACSR Scoter 636.0 30/7 1.019
ACSR Egret 636.0 30/19 1.019
AAC Arbutus 795 37 1.026   795
AAC Lilac 795  61  1.028
ACSR Stilt 715.5 24/7 1.036
ACSR Coot 795.0 36/1 1.040
AAAC SORA 833.6 37 1.051
ACSR Starling 715.5 26/7 1.051
ACSR Tern 795.0 45/7 1.063
CS    1000 58 1.070   800
ACSR Redwing 715.5 30/19 1.081
ACSR Cuckoo 795.0 24/7 1.092
AAC Cockscomb 900 37 1.092
ACSR Condor 795.0 54/7 1.092
AAC Snapdragon 900 61 1.094
AAAC Greely 927.2 37 1.108   954
ACSR Drake 795.0 26/7 1.108
AAAC SOLAR 927.2 37 1.108
AAC Magnolia 954 37 1.124
AAC Goldenrod 954 61 1.126
ACSR Ruddy 900.0 45/7 1.131
ACSR Mallard 795.0 30/19 1.140
AAC Hawkweed 1000 37 1.150   1000
AAC Camellia 1000 61 1.152
ACSR Canary 900.0 54/7 1.162
ACSR Rail 954.0 45/7 1.165
AAC Bluebell 1033.5 37 1.170
AAC Larkspur 1033.5 61 1.172
The data provided is consolidated from various cable manufacturers’ public data and is for reference only.  ASK Products makes no claim to the accuracy of the data provided.  Any reliance placed on the data contained in this guide is at user’s own risk.
